Table 31 Command output
Field Description
Line Params Set by User
Line parameters at ATU-R end, such as Standard, DMT Mode, Framing, and
Trellis Coding. You can only modify Standard for test or diagnosis, but not
the others.
The following information appears after the line is activated.
Actual Config Real operating parameters after the line is activated.
Rate(kbps)
Negotiation rate in kbps, with AS0 (DS) for the downlink and LS0 (US) for
the uplink.
Latency Latency mode: Fast or Interleave.
DMT Bits Allocation Per Bin Bits allocated to and carried by each bin.
display dsl status
Use display dsl status to display the status information of a specified DSL interface.
Syntax
display dsl status interface atm interface-number [ | { begin | exclude | include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
Parameters
interface-number: DSL interface number.
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Fundamentals Configuration Guide.
begin: Displays the first line that matches the specified regular expression and all lines that follow.
exclude: Displays all lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Example
# Display the status information of ADSL interface ATM 1/0.
<Sysname> display dsl status interface atm 1/0
Line Status: Loss Of Signal
Training Status: Idle
Active Params Near End Far End
Standard: G.dmt G.dmt
SNR (dB): 0.0 0.0
Attn(dB): 0.0 0.0
Pwr(dBm): 0.0 0.0
