R2511-HP MSR Router Series Interface Command Reference(V5)

263
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Fundamentals Configuration Guide.
begin: Displays the first line that matches the specified regular expression and all lines that follow.
exclude: Displays all lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Example
# Display the ADSL version information of interface ATM 1/0.
<Sysname> display dsl version interface atm 1/0
Adsl board chipset and version info:
Dsl Line Type: Adsl Over Pots
Chipset Vendor: BDCM
FW Release: A2pB017l.d15h
DSP Version: 17.1200
AFE Version: 1.0
Bootrom Version: 1.1
Hardware Version: 4.0
Driver Version: 1.3
CPLD Version: 1.0
Adsl Capability
ANNEX Supported :
ANNEX A
Standard Supported :
ANSI T1.413 Issue 2
ITU G992.1(G.dmt)
ITU G992.2(G.lite)
ITU G992.3(Adsl2)
ITU G992.3(ReAdsl2)
ITU G992.5(Adsl2p)
Table 33 Command output
Field Description
Adsl board chipset and version info The components and the version of the interface board.
DSL line Type Type of the user access line.
Chipset Vendor Identifier of the ADSL chipset vendor.
FW Release Identifier and version of the firmware.
Driver Version Version of the driver software.
CPLD Version Version of the logic.
Adsl Capability The standard and annex supported by the interface.
