ITU G991.2 ANNEX A: Supported
ITU G991.2 ANNEX B: Supported
Table 36 Command output
Field Description
Dsl line Type Type of the user access line.
ATM SAR Device Identifier of the SAR chip.
ATM SAR Revision Revision identifier of the SAR chip.
Chipset Vendor Identifier of the DSL chipset vendor.
Firmware Rel-Rev Identifier and version of the firmware.
CPLD Version Logic version.
Driver Version Driver software version.
ITU G991.2 ANNEX A, ITU G991.2 ANNEX B
Standards and the annexes supported by the
interface.
shdsl annex
Use shdsl annex to set the annex standard to be adopted by a G.SHDSL interface. You cannot activate
a link with different standard types at its two ends.
Use undo shdsl annex to restore the default.
Syntax
shdsl annex { a | b }
undo shdsl annex
Default
The annex standard is Annex B.
Views
ATM (G.SHDSL) interface view
Default command level
2: System level
Parameters
a: Specifies Annex A standard.
b: Specifies Annex B standard.
Usage guidelines
Annex A is dominant in North America and Annex B is dominant in Europe. When setting the annex
standard, you must consider the standard adopted in the region where your network is located. When
ATU-C and ATU-R use different standards, G.SHDSL cannot set up connection.
Examples
# Configure G.SHDSL interface ATM 1/0 to adopt annex A.
<Sysname> system-view
[Sysname] interface atm 1/0
