Frame-format: ESF, clock: slave, loopback: none
CT1 84 is down
Frame-format: ESF, clock: slave, loopback: none
Table 39 Command output
Field Description
Cpos4/0 current state: Current physical state of the CPOS interface.
Description: Interface description.
Frame-format SDH, multiplex AU-3,
clock master, loopback none
Physical layer information of the CPOS interface: the framing format
is set to SDH, AU-3 path is adopted, master clock (internal clock
signal) is used, and loopback is disabled.
SD threshold: 6 , SF threshold: 3 SD threshold and SF threshold of the CPOS interface.
Optical Transmission medium.
Regenerator section: Alarm and error statistics about the regenerator section.
Tx: J0 Sent overhead bytes.
Rx: J0 Received overhead bytes.
Alarm: Alarm statistics.
Error: Error statistics.
Multiplex section: Alarm and error statistics about the multiplex section.
Higher order path(VC-4-1):
Alarm and error statistics about the higher-order path. VC-4-1
indicates the AU-4 path is adopted. In the AU-4 path, there is one
higher-order path VC-4. The x in "VC-3-x" indicates the path
number. When adopting AU-3 path, one STM-1 has three
higher-order paths because it is multiplexed by three VC-3s.
CT1 1 is down Current physical state of T1 channel 1 of the CPOS interface 4/0.
Frame-format: ESF, clock: slave,
loopback: none
Physical layer information of T1 channels: the framing format is set
to ESF, master clock (internal clock signal) is used, and loopback is
disabled.
Related commands
• display controller cpos e1
• display controller cpos t1
display controller cpos e1
Use display controller cpos e1 to display the physical layer configuration information of an E1 channel
on a CPOS interface.
Syntax
display controller cpos cpos-number e1 e1-number [ | { begin | exclude | include } regular-expression ]
Views
Any view
