R2511-HP MSR Router Series Interface Command Reference(V5)

27
Parameters
inbound: Displays inbound traffic statistics.
outbound: Displays outbound traffic statistics.
interface-type: Specifies an interface type.
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Fundamentals Configuration Guide.
begin: Displays the first line that matches the specified regular expression and all lines that follow.
exclude: Displays all lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Usage guidelines
If an interface type is specified, this command displays traffic statistics for all interfaces of the specified
type.
If no interface type is specified, this command displays traffic statistics for all interfaces that have traffic
counters.
Examples
# Display inbound traffic statistics for all GigabitEthernet interfaces.
<Sysname> display counters inbound interface gigabitethernet
Interface Total(pkts) Broadcast(pkts) Multicast(pkts) Err(pkts)
GE1/1 100 100 0 0
GE1/2 0 0 0 0
GE1/3 Overflow Overflow Overflow Overflow
GE1/4 0 0 0 0
Overflow: more than 14 decimal digits(7 digits for column "Err").
--: not supported.
Table 8 Command output
Field Description
Interface Abbreviated interface name.
Total (pkts) Total number of packets received or sent through the interface.
Broadcast (pkts)
Total number of broadcast packets received or sent through the interface. On
an RPR physical port, all broadcast and multicast packets received or sent are
displayed as multicast packets.
Multicast (pkts)
Total number of multicast packets received or sent through the interface. On an
RPR physical port, all broadcast and multicast packets received or sent are
displayed as multicast packets.
Err (pkts) Total number of error packets received or sent through the interface.
Overflow: more than 14
decimal digits(7 digits for
column "Err").
The command displays Overflow if any of the following applies:
• The data length of an error statistic is greater than 7 decimal digits.
• The data length of a non-error statistic is greater than 14 decimal digits.
--: not supported. The statistical item is not supported.
