R2511-HP MSR Router Series Interface Command Reference(V5)

29
Field Description
Total (pkts/sec)
Average rate (in pps) of receiving or sending packets during the sampling
interval.
Broadcast (pkts/sec)
Average rate (in pps) of receiving or sending broadcast packets during the
sampling interval. On an RPR physical port, all broadcast and multicast
packets received or sent are displayed as multicast packets.
Multicast (pkts/sec)
Average rate (in pps) of receiving or sending multicast packets during the
sampling interval. On an RPR physical port, all broadcast and multicast
packets received or sent are displayed as multicast packets.
Overflow: more than 14
decimal digits.
The command displays Overflow if any of the following applies:
• The data length of an error statistic is greater than 7 decimal digits.
• The data length of a non-error statistic is greater than 14 decimal digits.
--: not supported. The statistical item is not supported.
Related commands
flow-interval
display port-group manual
Use display port-group manual to display information about port groups.
Syntax
display port-group manual [ all | name port-group-name ] [ | { begin | exclude | include }
regular-expression ]
Views
Any view
Default command level
2: System level
Parameters
all: Displays information about all port groups.
name port-group-name: Specifies the name of a port group, a string of 1 to 32 characters.
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Fundamentals Configuration Guide.
begin: Displays the first line that matches the specified regular expression and all lines that follow.
exclude: Displays all lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Usage guidelines
If the all keyword is specified, this command displays the name and member Ethernet interfaces of each
port group on the device.
If a port group is specified, this command displays its name and member Ethernet interfaces.
