44
WAN interface configuration commands
The following matrix shows the hardware and interface compatibility:
Hardware Su
pp
ort for interfaces
CE3 and CT3 interface modules
The modules do not support subrate configuration if the module
hardware version is earlier than Hardware 2.2.
MSR900 series Supports only the AUX and USB 3G/4G modem interfaces.
MSR93X series
The JG514A, JG515A and JG531A support serial interfaces.
The JG516A and JG517A support G.SHDSL interfaces.
The JG518A, JG519A, JG520A and JG597A support ADSL2+
interfaces.
The JG513A, JG515A, JG531A, JG517A, JG520A, JG596A and
JG665A support 3G/4G modem interfaces.
Only the JG597A supports ISDN BRI interface.
Common WAN interface configuration commands
bandwidth
Use bandwidth to set the expected bandwidth for the interface.
Use undo bandwidth to restore the default.
Syntax
bandwidth bandwidth-value
undo bandwidth
Views
Serial interface view, AUX interface view, AM interface view, Cellular interface view, E1-F interface view,
T1-F interface view, ISDN BRI interface view, CE3 interface view, CT3 interface view, CE1/PRI interface
view, CT1/PRI interface view
Default command level
2: System level
Parameters
bandwidth-value: Expected bandwidth for the interface, in the range of 1 to 4294967295 kbps.
Usage guidelines
You can obtain the expected bandwidth of an interface by querying the ifspeed value of the MIB node
with third-party software.
The expected bandwidth is used for bandwidth monitoring of the network management, but does not
affect the actual bandwidth of the interface.
