Field Description
The Maximum Transmit Unit is 1500, Hold
timer is 10(sec)
MTU of the AUX interface. The MTU defaults to 1500 bytes,
and a packet larger than the MTU is fragmented before it is
sent. If fragmentation is not allowed, the packet will be
dropped.
Hold timer refers to the lifetime of a packet in a network. It is
the maximum amount of time that a packet can exist in the
network before being dropped. The hold timer of packets on
the AUX interface is set to 10 seconds.
Internet Address is 6.6.5.5/24 Primary IP address of the AUX interface.
Link layer protocol is PPP Link layer protocol of the AUX interface.
LCP opened, IPCP opened A PPP connection is established successfully.
Output queue : (Urgent queuing :
Size/Length/Discards) 0/100/0
Urgent queuing: Current number of packets in the queue,
maximum number of packets that can stay in the queue, and
number of dropped packets.
Link layer protocol packets, such as PPP negotiation packets
and keepalive packets enter this queue.
Output queue : (Protocol queuing :
Size/Length/Discards) 0/500/0
Protocol queuing: Current number of packets in the queue,
maximum number of packets that can stay in the queue, and
number of dropped packets.
Packets with IP precedence 6 enter this queue.
Output queue : (FIFO queuing :
Size/Length/Discards) 0/75/0
FIFO queuing: current number of packets in the first-in first-out
(FIFO) queue, maximum number of packets that can stay in the
queue, and number of dropped packets.
Physical layer is asynchronous, Baudrate is
9600 bps
Physical layer status and bandwidth of the AUX interface.
Phy-mru is 1700
The maximum size of packets that the AUX interface can
receive is 1700 bytes.
Last clearing of counters: Never
The last time when the statistics on the AUX interface was
cleared.
Last 300 seconds input rate 0.00 bytes/sec,
0 bits/sec, 0.00 packets/sec
Average input rate in the last 300 seconds.
Last 300 seconds output rate 0.00 bytes/sec,
0 bits/sec, 0.00 packets/sec
Average output rate in the last 300 seconds.
