Field Description
Input: 0 packets, 0 bytes
0 broadcasts, 0 multicasts
0 errors, 0 runts, 0 giants
0 CRC, 0 align errors, 0 overruns
0 dribbles, 0 aborts, 0 no buffers
0 frame errors
Received statistics on the AUX interface:
• broadcasts—Number of received broadcast packets.
• multicasts—Number of received multicast packets.
• errors—Number of error packets detected on the physical
layer.
• runts—Number of undersized packets received on the
interface.
• giants—Number of oversized packets received on the
interface.
• CRC—Number of normal-sized packets with CRC errors
received on the interface.
• align errors—Number of packets with alignment errors
received on the interface.
• overruns—Number of packets dropped because the input
rate of the interface exceeded the queuing capability.
• aborts—Number of packets that are not received
successfully.
• no buffers—Number of packets that are discarded
because the buffer runs out.
• frame errors—Number of packets with frame errors.
Output:0 packets, 0 bytes
0 errors, 0 underruns, 0 collisions
0 deferred
Sent statistics on the AUX interface:
• errors—Number of error packets detected at the physical
layer.
• underruns—Number of packets that fail to be forwarded
because the interface reads from memory at a slower
speed than it forwards packets.
• collisions—Number of packets with collisions detected.
• deferred—Number of deferred or timeout packets.
DCD=DOWN DTR=UP DSR=DOWN
RTS=UP CTS= DOWN
Status of Data Set Ready (DSR), Data Terminal Ready (DTR),
Data Carrier Detect (DCD), Request to Send (RTS), and Clear
to Send (CTS) signals. For more information about DSR, DTR,
and DCD, see the detect c
ommand.
The brief information of interface(s) under
route mode:
Brief information about Layer 3 interfaces.
Link: ADM - administratively down; Stby -
standby
Link status:
• ADM—The interface has been administratively shut down.
To recover its physical state, use the undo shutdown
command.
• Stby—The interface is operating as a backup interface. To
see the primary interface, use the display standby state
command in High Availability Command Reference.
Protocol: (s) - spoofing
If the network layer protocol state of an interface is shown as
UP, but its link is an on-demand link or not present at all, its
protocol attribute includes the spoofing flag (an s in
parentheses).
Interface Abbreviated interface name.
