# Display brief information about serial interfaces, including their complete interface descriptions.
<Sysname> display interface serial brief description
The brief information of interface(s) under route mode:
Link: ADM - administratively down; Stby - standby
Protocol: (s) - spoofing
Interface Link Protocol Main IP Description
S7/0 UP UP(s) -- The interface for connecting RouterF.
S7/1 UP UP(s) -- --
Table 13 Command output
Field Descri
p
tion
Serial7/1 current state
Current physical state of the serial interface:
• DOWN (Administratively)—The serial interface was shut
down with the shutdown command.
• DOWN—The serial interface is physically down because
no physical link is present or the physical link has failed.
• UP—The serial interface is both administratively and
physically up.
Line protocol current state Link protocol state of the serial interface.
Description Description of the serial interface.
The Maximum Transmit Unit is 1500, Hold
timer is 10(sec)
The default MTU on the serial interface is 1500 bytes. Packets
larger than 1500 bytes are fragmented before being sent. If
fragmentation is not allowed, these packets will be dropped.
Hold timer refers to the lifetime of a packet in a network. It is
the maximum amount of time a packet can exist in the network
before being dropped. The hold timer of packets on the serial
interface is set to 10 seconds.
Internet Address is 9.9.9.6/24 Primary IP address of the serial interface.
Link layer protocol is PPP Link layer protocol of the serial interface.
LCP opened, IPCP opened A PPP connection is established successfully.
Output queue : (Urgent queuing :
Size/Length/Discards) 0/100/0
Urgent queuing specifies the current number of packets in the
queue, maximum number of packets that can stay in the
queue, and number of dropped packets.
Link layer protocol packets, such as PPP negotiation packets
and keepalive packets enter this queue.
Output queue : (Protocol queuing :
Size/Length/Discards) 0/500/0
Protocol queuing specifies the current number of packets in the
queue, maximum number of packets that can stay in the
queue, and number of dropped packets.
Packets with IP precedence 6 enter this queue.
Output queue : (FIFO queuing :
Size/Length/Discards) 0/75/0
FIFO queuing specifies the current number of packets in the
first-in first-out (FIFO) queue, maximum number of packets that
can stay in the queue, and number of dropped packets.
Physical layer is synchronous, Baudrate is
64000 bps
Physical layer status and bandwidth of the serial interface.
Interface is DCE, Cable type is V35, Clock
mode is DCECLK
Synchronizes the clock mode on the DCE side of the serial
interface.
