Table 14 Command output (WCDMA mode)
Field Description
Model 3G modem name.
International Mobile Subscriber Identity (IMSI) IMSI string of the SIM card.
International Mobile Equipment Identity (IMEI) IMEI serial number of the 3G modem.
Factory Serial Number (FSN) FSN of the 3G modem.
Modem Status
Status of the 3G modem:
• Online—The 3G modem is powered on.
• Offline—The 3G modem is powered off or in low power
mode. The cellular interface is unavailable.
Profile Information Parameter description template of the 3G modem.
Profile 1
PDP status of the 3G modem:
• ACTIVE—The parameter description template is already
configured.
• UNDEFINED—The parameter description template is not
configured yet. The cellular interface is not available. You
must use the profile create command to create the template,
namely, the profile.
PDP Type
PDP type (displayed only when Profile 1 = ACTIVE):
• IPv4.
• IPv6.
• PPP (transparent transmission).
Header Compression
PDP header compression mode:
• ON—Enables PDP header compression.
• OFF—Disables PDP header compression.
Data Compression
PDP data compression mode:
• ON—Enables PDP data compression.
• OFF—Disables PDP data compression.
Packet Session Status
Packet session status:
• Active—The 3G modem is transmitting data via PPP.
• Inactive—The 3G modem is physically down.
Current Service Status
Service status of the 3G modem:
• Service available—The modem provides services normally.
• Emergency—The modem provides limited services. The
cellular interface is unavailable.
• No service—The modem cannot provide services. The
cellular interface is unavailable.
• Low power—The modem is in low power mode. The
cellular interface is unavailable.
Current Service
Current service type:
• Circuit-switched—Available for the CS domain.
• Packet-switched—Available for the PS domain.
• Combined—Available for the CS and PS domains.
• Invalid.
