Field Description
Packet Service
PS domain attach/detach status of the 3G modem: detached
(the cellular interface is unavailable) or attached.
Current Roaming Status
• Roaming.
• Home.
Network Selection Mode
• Manual.
• Automatic.
Network Connection Mode
• WCDMA only.
• WCDMA precedence.
• GSM only.
• GSM precedence.
• Auto.
Current Network Connection
• No Service.
• GSM.
• GPRS.
• EDGE.
• WCDMA.
• HSDPA.
• HSUPA.
• HSDPA and HSUPA.
• HSPA+.
• Unknown.
Mobile Country Code
The Mobile Country Code (MCC) is displayed if the modem
has found the network. For example, the MCC of Mainland
China is 460.
Mobile Network Code
The Mobile Network Code (MNC) is displayed if the modem is
successfully registered with the network. For example, the
code of the GSM network of China Unicom is 01.
Location Area Code
The Location Area Code (LAC) is displayed if the modem is
successfully registered with the network.
Cell ID
The Cell ID is displayed if the modem is successfully registered
with the network.
Downstream Bandwidth Theoretical downlink bandwidth in bps.
Current Band
Current band selection mode:
• GSM.
• WCDMA.
• ANY.
• AUTO.
Current RSSI
Current RSSI:
• The RSSI range is –110dBm to –51dBm.
• Unknown: No signal. The cellular interface is unavailable.
PIN Verification
PIN authentication status:
• Disabled—PIN authentication is disabled.
• Enabled—PIN authentication is enabled.
