R2511-HP MSR Router Series Interface Command Reference(V5)

81
Field Description
PIN Status
• Ready—The USIM/SIM card is normal and has no
authentication request.
• PIN Requirement—The USIM/SIM card has a PIN
authentication request.
• PUK Requirement—The USIM/SIM card has a PUK
authentication request.
Number of Retries remaining Number of remaining retries for inputting the PIN or PUK code.
SIM Status
SIM card status:
• OK—The SIM card is normal.
• Network Reject—The SIM card is denied access to the
network. The cellular interface is unavailable.
• Not Insert—The SIM card is absent. The cellular interface is
unavailable.
# Display call connection information on interface Cellular 0/0 (CDMA mode).
<Sysname> display cellular 0/0 all
Modem State:
Hardware Information
====================
Model = EC169
Manufacturer = ****** TECHNOLOGIES CO.
Modem Firmware Version = 11.002.03.01.45
Hardware Version = CE62TCPUVer A
Electronic Serial Number (ESN) = c1836f2d
Preferred Roaming List (PRL) Version = 0
International Mobile Subscriber Identity (IMSI) = 460036101433925
Modem Status = Online
Network Information
===================
Current Service Status = Service available
Current Roaming Status = Home
Network Connection Mode = HYBRID
Current Network Connection = 1xRTT/EVDO HYBRID
Downstream Bandwidth = 3100000 bps
Radio Information
=================
Current RSSI(1xRTT) = -93 dBm
Current RSSI(EVDO) = -75 dBm
Current Voltage = 3336 mV
Modem Security Information
==========================
PIN Verification = Disabled
PIN Status = Ready
Number of Retries remaining = 3
UIM Status = OK
