Table 15 Command output (CDMA mode)
Field Description
Model 3G modem name.
International Mobile Subscriber Identity (IMSI) IMSI string of the SIM card.
Modem Status
Status of the 3G modem:
• Online—The 3G modem is powered on.
• Offline—The 3G modem is powered off or in low power
mode. The cellular interface is unavailable.
Current Service Status
Service status of the 3G modem:
• Service available—The modem provides services normally.
• Emergency—The modem provides limited services. The
cellular interface is unavailable.
• No service—The modem cannot provide services. The
cellular interface is unavailable.
• Low power—The modem is in low power mode. The
cellular interface is unavailable.
Current Roaming Status
• Roaming.
• Home.
Network Selection Mode
• Manual.
• Automatic.
Current Network Connection
• No Service.
• 1xRTT/EVDO HYBRID.
• EVDO.
• 1xRTT.
• Unknown.
Downstream Bandwidth Theoretical downlink bandwidth in bps.
Current RSSI (1xRTT)
Current RSSI of the 1xRTT network:
• The RSSI range is –125 dBm to –75 dBm.
• Unknown: No signal.
Current RSSI (EVDO)
Current RSSI of the EVDO network:
• The RSSI range is –120 dBm to –60 dBm.
• Unknown: No signal.
PIN Verification
PIN authentication status:
• Disabled—PIN authentication is disabled.
• Enabled—PIN authentication is enabled.
PIN Status
• Ready—The USIM/SIM card is normal and has no
authentication request.
• PIN Requirement—The USIM/SIM card has a PIN
authentication request.
• PUK Requirement—The USIM/SIM card has a PUK
authentication request.
Number of Retries remaining Number of remaining retries for inputting the PIN or PUK code.
