Field Description
Modem Status
Status of the 3G/4G modem:
• Online—The 3G/4G modem is powered on.
• Offline—The 3G/4G modem is powered off or in low
power mode. The cellular Ethernet interface is unavailable.
Profile Information Parameter description template of the 3G/4G modem.
Profile 1
PDP status of the 3G/4G modem:
• ACTIVE—The parameter description template is already
configured.
• UNDEFINED—The parameter description template is not
configured yet. The cellular Ethernet interface is
unavailable. You must use the profile create command to
create the template, namely, the profile.
PDP Type
PDP type (displayed only when Profile 1 = ACTIVE):
• IPv4.
• IPv6.
• PPP (transparent transmission).
Header Compression
PDP header compression mode:
• ON—Enables PDP header compression.
• OFF—Disables PDP header compression.
Data Compression
PDP data compression mode:
• ON—Enables PDP data compression.
• OFF—Disables PDP data compression.
Packet Session Status
Packet session status:
• Active—The 3G/4G modem is transmitting data through
PPP.
• Inactive—The 3G/4G modem is physically down.
Authentication Authentication mode specified in the profile.
Username Username assigned by the authenticator.
Current Service Status
Service status of the 3G/4G modem:
• Service available—The modem provides services correctly.
• Limited—The modem provides limited services. The cellular
Ethernet interface is unavailable.
• No service—The modem cannot provide services. The
cellular Ethernet interface is unavailable.
• Low power—The modem is in low power mode. The
cellular Ethernet interface is unavailable.
• Limited Regional Service—The modem provides limited
regional services.
• Unknown—Unknown service status.
