96
Table 22 Command output
Field Descri
p
tion
LLDP tlv-config of port 162 Advertisable optional TLVs of port 162.
NAME TLV type.
STATUS Indicates whether a specific type of TLV is sent through a port.
DEFAULT Indicates whether a specific type of TLV is sent through a port by default.
Basic optional TLV
Basic TLVs:
• Port description TLV.
• System name TLV.
• System description TLV.
• System capabilities TLV.
• Management address TLV.
IEEE 802.1 extended TLV
IEEE 802.1 organizationally specific TLVs:
• Port VLAN ID TLV.
• Port and protocol VLAN ID TLV.
• VLAN name TLV.
• Management VID TLV.
IEEE 802.3 extended TLV
IEEE 802.3 organizationally specific TLVs:
• MAC-Physic TLV.
• Power via MDI TLV.
• Link aggregation TLV.
• Maximum frame size TLV.
LLDP-MED extend TLV
LLDP-MED TLVs:
• Capabilities TLV.
• Network Policy TLV.
• Extended Power-via-MDI TLV.
• Location Identification TLV.
• Inventory TLV.
Inventory TLV
Inventory TLVs:
• Hardware Revision TLV.
• Firmware Revision TLV.
• Software Revision TLV.
• Serial Number TLV.
• Manufacturer Name TLV.
• Model name TLV.
• Asset id TLV.
lldp admin-status
Use lldp admin-status to specify the LLDP operating mode.
Use undo lldp admin-status to restore the default.
