HP MSR2000/3000/4000 Router Series Layer 2 - LAN Switching Command Reference

17
Field Descri
p
tion
Port edged
The port is an edge port or non-edge port.
• Config—Configured value.
• Active—Actual value.
Point-to-Point
The port is connected to a point-to-point link or not.
• Config—Configured value.
• Active—Actual value.
Transmit limit Maximum number of packets sent within each hello time.
Protection type
Protection type on the port:
• Root—Root guard.
• Loop—Loop guard.
• BPDU—BPDU guard.
• None—No protection.
TC-Restriction Status of TC transmission restriction on the port.
Role-Restriction Status of port role restriction on the port.
MST BPDU format
Format of the MST BPDUs that the port can send:
• Config—Configured value (legacy or 802.1s).
• Active—Actual value (legacy or 802.1s).
Port Config-
Digest-Snooping
Status of digest snooping on the port.
Rapid transition Indicates whether the port rapidly transits to the forwarding state in the MSTI.
Num of VLANs
mapped
Number of VLANs that are mapped to the MSTI.
Port times
Major parameters for the port:
• Hello—Hello timer.
• MaxAge—Maximum age timer.
• FwdDelay—Forward delay timer.
• MsgAge—Message age timer.
• RemHops—Remaining hops.
BPDU sent Statistics on sent BPDUs.
BPDU received Statistics on received BPDUs.
RegRoot ID/IRPC MSTI regional root/internal path cost.
Root Type
MSTI root type:
• Primary root.
• Secondary root.
Master bridge MSTI root bridge ID.
Cost to master Path cost from the MSTI to the master bridge.
TC received Number of received TC BPDUs.
Protocol status Spanning tree protocol status.
Protocol Std. Spanning tree protocol standard.
Version Spanning tree protocol version.
