23
Table 10 Command output
Field Descri
p
tion
Port Port name.
Role change
Role change of the port ("Aged" means that the change was caused by expiration
of the received configuration BPDU).
Time Time of port role calculation.
Port priority Port priority.
display stp region-configuration
Use display stp region-configuration to display the effective configuration information of the MST region,
including the region name, revision level, and user-configured VLAN-to-instance mappings.
Syntax
display stp region-configuration
Views
Any view
Predefined user roles
network-admin
network-operator
Examples
# In MSTP mode, display effective MST region configuration information.
<Sysname> display stp region-configuration
Oper Configuration
Format selector : 0
Region name : hello
Revision level : 0
Configuration digest : 0x5f762d9a46311effb7a488a3267fca9f
Instance VLANs Mapped
0 21 to 4094
1 1 to 10
2 11 to 20
Table 11 Command output
Field Descri
p
tion
Format selector
Format selector that is defined by the spanning tree protocol. The default value
is 0, and the selector cannot be configured.
Region name MST region name.
Revision level
Revision level of the MST region. The default value is 0, and the level can be
configured by using the revision-level command.
VLANs Mapped VLANs mapped to the MSTI.
