64
Field Description
Internet protocol processing : disabled
The interface is not capable of processing IP packets. This
information is displayed when the interface is not configured with
an IP address.
Internet Address is 192.168.1.54/24
Primary
The primary IP address of the interface is 192.168.1.54/24. This
information is displayed only if the primary IP address is configured
for the interface.
P Packet Frame Type IPv4 outgoing frame format.
Hardware Address MAC address that corresponds to a VLAN interface.
IPv6 Packet Frame Type IPv6 outgoing frame format.
Last clearing of counters
Time when the reset counters interface vlan-interface command
was last used to clear the interface statistics.
Never indicates the reset counters interface command has never
been used on the interface since the device’s startup.
Brief information on interface(s) under
route mode
Brief information about Layer 3 interfaces.
Link: ADM - administratively down; Stby
– standby
Link layer state of the interface:
• ADM—The interface has been administratively shut down. To
recover its physical state, run the undo shutdown command.
• Stby—The interface is operating as a standby interface.
Protocol: (s) - spoofing
If the network layer protocol state of an interface is shown as UP,
but its link is an on-demand link or not present at all, its protocol
attribute includes the spoofing flag (which is a letter s in
parentheses).
Interface Abbreviated interface name.
Link
Physical link state of the interface:
• UP—The link is up.
• ADM—The link has been administratively shut down. To recover
its physical state, run the undo shutdown command.
Protocol
Protocol connection state of the interface:
• UP.
• DOWN.
• UP(s).
Main IP Main IP address of the interface.
Description Description of the interface.
Related commands
reset counters interface vlan-interface
display vlan
Use display vlan to display VLAN information.
