82
Field Descri
p
tion
P0- P1- P2- P3- P4- P5- P6-
P7-
Number of supported priorities configured by using the
priority-flow-control no-drop dot1p dot1p-list command at the local end.
Number of traffic classes
supported
Capability set supported by PFC (displayed only in Rev 1.01).
Priority 802.1p priority.
Protocol ID Application protocol number.
CoS map Application protocol-to-CoS mapping.
CBS
Indicates whether the token bucket mechanism is supported on the port:
•
False—The token bucket mechanism is not supported.
• True—The token bucket mechanism is supported.
Max TCs Maximum number of priorities supported.
TSA Transmission selection algorithm.
Value of MBC
MBC indicates the ability of packets to bypass MACsec. It is 1-bit long.
• 0—Packets can bypass MACsec when MACsec is disabled.
• 1—Packets cannot bypass MACsec when MACsec is disabled.
Auto-negotiation supported Indicates whether auto-negotiation is supported on the port.
Auto-negotiation enabled Indicates whether auto-negotiation is enabled on the port.
OperMau Speed and duplex state of the port.
Power port class
PoE device type:
• PSE—Power sourcing equipment.
• PD—Powered device.
PSE power supported Indicates whether the device can operate as a PSE.
PSE power enabled Indicates whether the device is operating as a PSE.
PSE pairs control ability Indicates whether the PSE-PD pair control is available.
Power pairs
PoE mode:
• Signal—PoE over signal lines.
• Spare—PoE over spare lines.
Port power classification
Port power classification of the PD:
• Class 0.
• Class 1.
• Class 2.
• Class 3.
• Class 4.
display lldp neighbor-information
Use display lldp neighbor-information to display the LLDP information carried in LLDP TLVs that the local
device receives from the neighboring devices.
