86
Field Descri
p
tion
Chassis type
Chassis ID representation:
• Chassis component.
• Interface alias.
• Port component.
• MAC address.
• Network address (ipv4).
• Interface name.
• Locally assigned—Locally-defined chassis type other than those
listed above.
Chassis ID
ID that identifies the LLDP sending device, which can be a MAC
address, a network address, an interface or some other value
depending on the chassis type of the neighboring device.
Port ID type
Port ID representation:
• Interface alias.
• Port component.
• MAC address.
• Network address (ipv4).
• Interface name.
• Agent circuit ID.
• Locally assigned—Locally-defined port ID type other than those
listed above.
Port ID Value of the type of the port ID.
System name System name of the neighboring device.
System description System description of the neighboring device.
System capabilities supported
Capabilities supported on the neighboring device:
• Bridge—Switching is supported.
• Router—Routing is supported.
System capabilities enabled
Capabilities enabled on the neighboring device:
• Bridge—Switching is enabled.
• Router—Routing is enabled.
Port and protocol VLAN ID(PPVID) Port protocol VLAN ID.
Port and protocol VLAN supported Indicates whether protocol VLAN is supported on the port.
Port and protocol VLAN enabled Indicates whether protocol VLAN is enabled on the port.
VLAN name of VLAN 2 Name of VLAN 2.
OperMau Speed and duplex state on the port.
Power port class
PoE device type:
• PSE—Power sourcing equipment.
• PD—Powered device.
PSE power supported Indicates whether the device can operate as a PSE.
PSE power enabled Indicates whether the device is operating as a PSE.
PSE pairs control ability Indicates whether the PSE-PD pair control is available.
