93
Table 21 Command output
Field Descri
p
tion
Bridge mode of LLDP LLDP bridge mode: service-bridge or customer-bridge.
Global status of LLDP Indicates whether LLDP is globally enabled.
LLDP neighbor information last
changed time
Time when the neighbor information was last updated.
Transmit interval LLDPDU transmit interval.
Hold multiplier TTL multiplier.
Reinit delay LLDP re-initialization delay.
Transmit max credit Token bucket size for sending LLDPDUs.
Trap interval Trap transmit interval.
Fast start times
Number of LLDPDUs sent each time fast LLDPDU transmission is
triggered.
Port status of LLDP Indicates whether LLDP is enabled on the port.
Admin status
LLDP mode of the port:
• TxRx—The port can send and receive LLDPDUs.
• Rx_Only—The port can only receive LLDPDUs.
• Tx_Only—The port can only send LLDPDUs.
• Disable—The port cannot send or receive LLDPDUs.
Trap Flag Indicates whether trapping is enabled.
Polling interval LLDP polling interval, which is 0 when LLDP polling is disabled.
Number of neighbors Number of LLDP neighbors connecting to the port.
Number of MED neighbors Number of MED neighbors connecting to the port.
Number of CDP neighbors Number of CDP neighbors connecting to the port.
Number of sent optional TLV Number of optional TLVs contained in an LLDPDU sent through the port.
Number of received unknown TLV Number of unknown TLVs contained in a received LLDPDU.
display lldp tlv-config
Use display lldp tlv-config to display the types of advertisable optional LLDP TLVs of a port.
Syntax
display lldp tlv-config [ interface interface-type interface-number ] [ agent { nearest-bridge |
nearest-customer | nearest-nontpmr } ] ]
Views
Any view
Predefined user roles
network-admin
network-operator
