317
[RouterB-Ethernet1/1] bfd min-receive-interval 500
[RouterB-Ethernet1/1] bfd detect-multiplier 9
[RouterB-Ethernet1/1] quit
[RouterB] ipv6 route-static 121:: 64 ethernet 1/1 FE80::2A0:FCFF:FE00:580A bfd
control-packet
[RouterB] ipv6 route-static 121:: 64 13::2 preference 65
[RouterB] quit
# Configure IPv6 static routes on Router C.
<RouterC> system-view
[RouterC] ipv6 route-static 120:: 64 13::1
[RouterC] ipv6 route-static 121:: 64 10::102
Verifying the configuration
# Display BFD sessions on Router A.
<RouterA> display bfd session
Total Session Num: 1 Up Session Num: 1 Init Mode: Active
IPv6 Session Working Under Ctrl Mode:
Local Discr: 513 Remote Discr: 33
Source IP: FE80::2A0:FCFF:FE00:580A (link-local address of Ethernet1/1 on Router
A)
Destination IP: FE80::2E0:FCFF:FE58:123E (link-local address of Ethernet1/1 on Router
B)
Session State: Up Interface: Eth1/2
Hold Time: 2012ms
The output shows that the BFD session has been created.
# Display IPv6 static routes on Router A.
<RouterA> display ipv6 routing-table protocol static
Summary Count : 1
Static Routing table Status : <Active>
Summary Count : 1
Destination: 12::/64 Protocol : Static
NextHop : 12::2 Preference: 60
Interface : Eth1/1 Cost : 0
Static Routing table Status : <Inactive>
Summary Count : 0
The output shows that Router A communicates with Router B through Ethernet 1/1. The link over Ethernet
1/1 fails.
# Display IPv6 static routes on Router A.
<RouterA> display ipv6 routing-table protocol static
