HP NetRAID-1M Controller Product Brief (12/17/02)

specifications
RAID levels supported 0, 1, 5, 10, and 50
SCSI connectors One 68-pin, high-density internal connector; One 68-pin, very-high-
density external connector
SCSI channels One
Devices per SCSI channel Up to 14
SCSI device types supported Synchronous or asynchronous
SCSI bus Single-ended or LVD
SCSI data transfer rate Fast, Ultra, Ultra2, Ultra3
SCSI termination SCSI active termination
Termination disable Through jumper configuration
Card size 6.875" × 4.2" (half-length PCI)
Multiple cards Up to six HP NetRAID family adapters (varies by server)
Bus type PCI 2.1 (32-bit bus), 33 MHz
Bus data transfer rate Up to 132 MB/sec
Processor Intel
®
i960RM @ 100 MHz
Cache configuration 32 MB SDRAM
Nonvolatile RAM 32K × 8 to store RAID configuration
BIOS HP NetRAID BIOS
Tone generator Audible warnings indicate degraded drives, offline drives, and drive
rebuilds
Warranty 1-year return to HP or system matching when installed in an
HP Netserver
supported operatin
g
systems
Microsoft Windows NT 4.0 and Windows 2000; Novell NetWare, 5.1, 6.0; SCO O
p
enServer 5.x;
SCO UnixWare 7.x; and Red Hat Linux 7.0*.
* Only available on HP Server LP1000r and HP Server LP2000r
supported servers
E200, E60, E800, tc2100, tc2110, tc3100, tc4100, LC3, LC2000, LH3, LH3000, LH4, LH6000,
LPr, LP1000r, LP2000r, LT 6000r, LXr 8000, LXr 8500
