HP Netserver AA 6200 Solutions Release Notes v4.0 SP1

8 Endurance Release Notes for Release 4.0 Service Pack 1
Optional Endurance Kit Contents for 10 Kilometer SplitSite Configurations
If you have purchased the support for long distance SplitSite configurations of up to10 kilometer
separation of the tuples, the content of your Endurance kit is different from that described in the
Release 4.0 HP Netserver AA Solution Installation Guide.
Note: If you have not purchased the optional long distance SplitSite product, the content
of your Endurance kit is as described in the Release 4.0 HP Netserver AA Solution
Installation Guide.
For long distance SplitSite installations only, the Endurance Accessory Kit includes two
loopback plugs to be used if you want to perform BIOS loopback tests.
On page 1-14 of the Release 4.0 HP Netserver AA Solution Installation Guide, replace the
section Unpacking Your Endurance Server Kit with the following section applicable to long
distance SplitSite configurations. Changes from the previous version are shown in bold face.
Unpacking Your Endurance Server Kit
After Planning the SCSI Disk and CD-ROM Configurations, unpack your Endurance server kit
and make sure that you receive:
Table 6 Endurance Server Kit Contents
Quantity Part
4 MICs (Marathon Interface Cards)
4 MIC cables –2 local and 2 remote
Two fiber optic cables are 5 meters, and two are 10 meters
* in length.
* The 10 meter cables are used in long distance SplitSite installation for
staging purposes only.
1 IL (IOP Link) cable – Category 5 UTP cross-over (Ethernet) cable for use in fast
Ethernet connections, approximately 8 meters in length
1
IL (IOP Link) fiber – Multimode
* fiber for use in gigabit Ethernet, 8 meters in length
Note: You use either of the above Ethernet connections, depending on whether
you have fast Ethernet or gigabit Ethernet.
* The multimode fiber is used in long distance SplitSite installations for staging
purposes only.
1 Endurance CD-ROM
