Table 7 explains how to install the long distance SplitSite Endurance server cables.
Table 7 Long Distance SplitSite Endurance Server Cables
Cable Description Connects Installation Instructions
MIC cables
4 singlemode patch
cords (that you obtain),
with an MT-RJ
connector on one end,
which attaches to the
MIC, and a connector at
the other end that will fit
the type of patch panel
you are using – for
example, an SC, FC, ST,
or LC connector.
IOP1 to CE2 via
the patch panel
1. Attach an MT-RJ cable
connector on the singlemode
patch cord to the IOP1 MIC
port labeled REMOTE.
2. Attach the other end of that
patch cord to the patch panel
port intended for CE2.
CE1 to IOP2 via
the patch panel
1. Attach an MT-RJ cable
connector on the singlemode
patch cord to the CE1 MIC
port labeled REMOTE.
2. Attach the other end of that
patch cord to the patch panel
port intended for IOP2.
IOP2 to CE1 via
the patch panel
1. Attach an MT-RJ cable
connector on the single
mode patch cord to the IOP2
MIC port labeled REMOTE.
2. Attach the other end of that
patch cord to the patch panel
port intended for CE1.
CE2 to IOP1 via
the patch panel
1. Attach an MT-RJ cable
connector on the single
mode patch cord to the CE2
MIC port labeled REMOTE.
2. Attach the other end of the
IOP1 patch cord to the patch
panel.
