Unpacking Your Endurance Server Kit
After Planning the SCSI Disk and CD-ROM Configurations, unpack your Endurance server kit
and make sure that you receive:
Using the labels from the Endurance server kit, apply the appropriate labels to the monitors,
front panels, and back panel of each IOP and CE.
Continue with Completing Initial Power-On Self Test.
Table 1-4 Endurance Server Kit Contents
Quantity Part
4 MICs (Marathon Interface Cards)
4 MIC cables –2 local and 2 remote
Two fiber optic cables are 5 meters, and two are 10 meters in length.
1 IL (IOP Link) cable – Category 5 UTP cross-over (Ethernet) cable for use in fast
Ethernet connections, approximately 8 meters in length
1 IL (IOP Link) fiber – Multi-mode fiber for use in gigabit Ethernet, 8 meters in length
Note: You use either of the above Ethernet connections, depending on whether
you have fast Ethernet or gigabit Ethernet.
1 Endurance CD-ROM
1 Endurance documentation, including the Endurance Release Notes, HP Netserver AA
Solution Administrator’s Guide, and this manual
1 Endurance Accessory Kit that contains the labels for the Endurance server computers
