HP Netserver AA Solution Installation Guide v4.0 SP1

Installing the Hardware 2-7
Table 2-1 Endurance Server Cables
Cable Description Connects Installation Instructions
MIC
Cables
2 local fiber optic
cables
2 remote fiber optic
cables
Note:
The 5 meter cables
are intended for
local use, while the
10 meter cables
are intended for
remote use.
However, the
cables are
interchangeable if
distance is not an
issue.
IOP1 to CE1
1. Attach a cable connector to the IOP1 port
labeled LOCAL.
2. Attach the other end of the cable to the LOCAL
port on CE1.
IOP2 to CE2
1. Attach a cable connector to the IOP2 port
labeled LOCAL.
2. Attach the other end of the cable to the
LOCAL port on CE2.
IOP1 to CE2 1. Attach a cable connector to the IOP1 port
labeled REMOTE.
2. Attach the other end of the cable to the
REMOTE port on CE2.
IOP2 to CE1
1. Attach a cable connector to the IOP2 port
labeled REMOTE.
2. Attach the other end of the cable to the
REMOTE port on CE1.
IL Cable Category 5 UTP
cross-over
(Ethernet) cable
OR
Fiber (gigabit
Ethernet) cable
IL Ethernet
adapters on
IOP1 and
IOP2
1. Attach one end of the cable to the IL Ethernet
adapter port on IOP1.
2. Attach the other end of the cable to the IL
Ethernet adapter port on IOP2.
Use the appropriate cable, depending on the type
of IL Ethernet adapter you have.
Be sure to connect the adapters that support the
IL and not the adapters that connect your server
to the network.
