2-8 HP Netserver AA Solution Installation Guide
Figure 2-1 is a cabling example of the Endurance server. The figure includes monitors and
keyboards attached to the CE, which is an optional configuration.
Figure 2-1 Endurance Server Cabling
For information about cabling the Endurance server with a KVM switch, see Appendix A.
Continue with Completing Hardware Installation.
IOP
CE
Tuple 2
To the network
IL cable
Tuple 1
IOP
CE
MIC cable
MIC cable
