HP Netserver AA Solution Installation Guide v4.0 SP1

3-12 HP Netserver AA Solution Installation Guide
Table 3-1 Network Adapter Bindings
Adapter Description Binding Configuration
IOP Link Adapter
(IL)
The Ethernet adapter that
services the IOP Link and
provides private network
connectivity between the
IOPs.
Enable
- Endurance IOP Link Driver
- Endurance Datagram Service
- NetBEUI or TCP/IP
For the TCP/IP protocol, you must specify the
IP addresses because there is no DHCP
server.
- Client for Microsoft Networks
- File and Printer Sharing for Microsoft
Networks
Disable
- Endurance Ethernet Provider
See Figure 3-1.
Be sure the Ethernet adapters that service the IL
are configured to 100 Mbps or gigabit and Full
Duplex.
Redirected
Ethernet adapter
Any Ethernet adapters that
provide LAN connectivity
for the CEs.
Enable
- Endurance Ethernet Provider
- Endurance Datagram Service
Disable
- IOP Link Driver
- All other services and protocols
See Figure 3-2.
