Note: You can bind MtcDgs to a maximum of five Ethernet adapters.
Figure 3-1, Figure 3-2, Figure 3-3, and Figure 3-4 provide examples of the adapter binding
configurations.
Endurance Virtual
Network Provider
(MtcVnP)
Virtual LAN between the
IOP and the CEs which
provides a private point-to-
point network.
Enable
- NetBEUI or TCP/IP
For the TCP/IP protocol, you must specify the
IP addresses because there is no DHCP
server.
- Client for Microsoft Networks
- File and Printer Sharing for Microsoft
Networks
Disable
- Endurance IOP Link Driver
- Endurance Ethernet Provider
- Endurance Datagram Service
See Figure 3-3.
IOP Ethernet
adapter
Any network adapter that is
not configured for the IOP
Link (IL) or as a redirected
adapter.
Enable
- Endurance Datagram Service
- NetBEUI or TCP/IP
- Client for Microsoft Networks
- File and Printer Sharing for Microsoft
Networks
Disable
- Endurance Ethernet Provider
- IOP Link Driver
See Figure 3-4.
Table 3-1 Network Adapter Bindings (Continued)
