HP Netserver LH 3 NetRAID-3Si Config Guide for Windows NT4.0 Clusters

2
System software:
Navigator version L.15.15 or later (350-450 MHz with 40 MB/Sec SCSI controller board)
L.16.00 or later (400 or 450 MHz with 80 MB/Sec SCSI controller board)
L.16.05 or later (500, 550, 600 MHz with 40 MB/Sec SCSI controller board)
Operating System Microsoft Windows NT Server 4.0, Enterprise Edition
Service pack SP4 or later
SPU
Model HP NetServer LH3
Clock speed 350, 400, 450 MHz with Rack Storage/12 D5989A
400, 450, 500, 550, 600 MHz with Rack Storage/12 D5989B
No. of CPUs 2
BIOS version 4.06.28PL or later (350-450 MHz with Rack Storage/12 D5989A)
4.06.14PL or later (400 or 450 MHz with Rack Storage/12 D5989B)
4.06.33PL or later (400, 450, 500, 550, 600 with Rack Storage/12 D5989B
CPU cache Any size
RAM 128 MB minimum. Must be HP.
No. of power supplies 2 required, 3 for redundancy
Local storage Internal or external, using any controller except embedded RAID or a
NetRAID-3Si. Must use HP disks. See
Local Storage below.
I/O slots: P7 – P8 Shared storage controller
P1 – Intra-cluster (Heartbeat) LAN
P2 – Client LAN
All others – Any other plug-in cards.
Storage
Local
Controller and Cabinets
(physical drive location)
May use Embedded SCSI, NetRAID 1, NetRAID-1Si or NetRAID 3 in
PCI slot P8 for internal storage or with a Rack Storage/8, otherwise any
controller listed on the HP Tested Products List.
May not use Embedded RAID or NeRAID-3Si for internal storage or
external with a Rack Storage/12.
Disk drives (hot swap
or fixed)
HP only
SCSI bus Any HP cables that meet SCSI specifications and any SCSI bus speed.
SCSI IDs Any
Shared
Controller
Model HP NetRAID-3Si Adapter D5955A
No. of controllers 1
Firmware W.01.20
BIOS B.01.10
Driver 2.22
NetRAID Assistant A.01.15 or later
SPU I/O slot P7 - P8
SCSI ID 6, 7
Channels 0, 1, 2
