HP Netserver LH 3000 FC Config Guide for Windows 2000 Advanced Server Clusters

HP Rack Storage/12 Optional

Number of cabinets: 1 – 2

Model HP Rack Storage/12 – D5989B

plus two D6025B SCSI cards for each cabinet

Status SCSI ID 5 (fixed)

Disk SCSI IDs 0 – 3, 8 – 15 (fixed)

Disk drives: Same as HP Rack Storage/12FC

Cables Any HP LVD SCSI cables from the following list:

1 meter D7131A

2.5 meter D6020A

5 meter D6982A

10 meter D6983A

LANs

Intra-cluster (Heartbeat) LAN Client LAN

LAN connection HP D5954A crossover cable or any

equivalent.

Any LAN

The intra-cluster LAN may only be

used for cluster node

communication via a crossover

cable or VLAN. It may not be used

for client communication.

NIC:

Model Embedded NIC Any that is on both the HP

Tested Products List and the

Microsoft Hardware

Compatibility List.

For SPOFless, use D5013A/or B.

Driver Hptxnt5.sys 4.01.67 (Windows 2000

A.S. CD) or later

For SPOFless, use hptxnt5.sys

version 4.2.27.0 (Navigator

L.18.04.5) or later.

The vendor supported driver.

NOTE If the NIC used is the

same type as the embedded NIC

(D5013A/B), then the Client

LAN NIC must use the same

driver as the Intra-cluster NIC.

No. of NICs 1 1 minimum

For SPOFless, 2 NICs

configured as a fault tolerant

team are recommended.

Shared Storage Cabling

This part of the guide defines the cabling configurations for clusters using the HP NetServer

LH 3000 and HP Rack Storage/12FC. Only these cabling configurations and these cables are supported.
