HP Netserver LPr Quick Service Guide

Remote Control Card

Refer to the Top Tools Administration Guide for Remote Control along with the upgrade kit documentation for

information on the remote control card.

IPMI/ I C Connector

Route cable through open spaces

to PCI area. DO NOT route the

cable over the top of sheet

metal walls.

HP NetRAID Card

NOTE If there are other SCSI controllers on the PCI bus, the slot will affect boot order. See the Boot

Device Priority.

SCSI Repeater Card

SCSI Cable

HP NetRAID

Adapter
