HP Netserver LXr Pro8 User Guide

iii
Contents
1 Setting Up the HP NetServer LXr Pro8........................................................1
Before You Set Up Your HP NetServer..........................................................1
Setup Steps ...................................................................................................1
2 Controls, Indicators, and Ports....................................................................5
Front Panel Controls ......................................................................................5
Power Supply Indicators.................................................................................7
Rear Panel Controls, Ports, and Indicators.....................................................8
Power-Up and Power-Down Procedures.......................................................10
Power-Up Procedure................................................................................10
Power Down Procedure............................................................................11
Connecting AC Power to Multiple-Server Configurations..........................12
3 Opening and Closing the HP NetServer ...................................................15
Multiple Points of Access .............................................................................15
Removing and Replacing the Front Bezel ....................................................15
Undocking the Satellite Chassis ...................................................................16
Redocking the Satellite Chassis ...................................................................19
Detaching and Reattaching the Satellite Chassis..........................................21
Opening or Removing the Satellite Chassis' Top Cover ...............................24
Accessing the Lower Board Cage.................................................................27
4 Installing Mass Storage ..............................................................................29
Types of Devices That Can Be Installed.......................................................29
Boot Device Priority .....................................................................................29
Setting the Device's SCSI Device ID............................................................30
Installing an Internal Hard Disk Drive ...........................................................30
Installing the First or Second Drive in the Server .....................................30
Installing Hard Drives in all Three Bays....................................................32
5 Installing Additional Memory .....................................................................35
Introduction..................................................................................................35
Installation Basics ........................................................................................35
Tools Required.............................................................................................38
Removing the Memory Board ......................................................................38
Installing 128 MB SDRAM DIMMs on the 4 GB Memory Board ....................40
