Chapter 3 Opening and Closing the

HP NetServer

NOTE If the satellite refuses to slide all the way forward, check that

you have placed it correctly on its slides. Also make sure that

you pressed in the release levers on both slides.

12. Replace the retention bracket as shown in Figure 3-2.

13. Relock the power interlock switch on the HP NetServer's rear panel. To do

this, turn the switch counter-clockwise as far as it will go.

14. At the front, relatch the power supplies. Ensure the indicator lights on the

power supplies come up correctly during the power-up procedure before

reattaching the front bezel. See "Power Supply Indicators" in Chapter 1.

Opening or Removing the Satellite Chassis' Top

Cover

The satellite chassis' top cover swings open on hinges. You can swing open the

cover and leave it attached to the satellite, or remove the cover entirely.

To open or remove the cover:

1. Extend the HP NetServer's satellite chassis for service, or detach it

entirely from the base chassis. (See the previous section for details.) The

cover does not open until you extend or detach the satellite chassis.

NOTE You must pull the satellite at least several inches out before its

top cover can be opened.

2. Stand behind the satellite chassis. Place a finger in each of the two

fingerholds on the chassis' top cover.

3. Push both fingerholds toward the center of the panel. The fingerholds

slide inward a fraction of an inch. See Figure 3-7.
