HP Netserver LXr Pro8 User Guide

Chapter 7 Mounting the Server in the Rack
59
HP NetServer Rack Mount Parts List
The rack-mount kit that accompanies the HP NetServer should contain the
following parts:
Table 7-1. Parts for Rack Mount Kit
Quantity Description
2 Rails
8 10x32 Tinnerman nuts (sheet metal nuts)
4 10x32 flat-head Phillips screws
8 10x32 Torx screws
4 M4 flat-head 5mm Phillips screws
Installation Procedure
Step 1: Attaching the Rails
1. Use the HP Rack Assistant software to determine where in the rack to
mount the HP NetServer.
In the rack's right-hand rear column, fasten two Tinnerman nuts in the
center holes of the bottom two EIA units reserved for the server. Fasten
the nuts to the side of the rack column, not the rear.
