A Adapter Specifications
HP NetRAID-3Si Specifications
Parameter Specification
Product Number D5955A
Card Size 12.3" x 4.2" (full length PCI)
Processor Intel i960RD™ @ 66 MHz
Bus Type PCI 2.1
PCI Adapter Custom ASIC
Bus Data Transfer Rate Up to 132 MB
BIOS HP NetRAID BIOS
Cache Configuration 16 MB using 60 ns EDO DRAM
Firmware 1 MB flash ROM
Nonvolatile RAM 32 KB of NVRAM for disk configuration space
Operating Voltage 5.00 V ± 0.25 V
SCSI Controllers Symbios Logic 53C895 on each channel
SCSI Data Transfer Rate Up to 80 MB/sec with Ultra2 drives; 40 MB/sec with Ultra drives
SCSI Bus Low voltage differential or single-ended SCSI
SCSI Termination Active
Termination Disable Automatic through cable detection
Devices per SCSI Channel 6 to 8, depending on SCSI mode and storage cabinet
SCSI Device Types
Supported
Low voltage differential or single-ended SCSI disk drives
SCSI Channels Three
RAID Levels Supported 0, 1, 3, 5,10, 30, and 50
SCSI Connectors Three 68-pin, high-density internal connectors
Three 68-pin, ultra-high-density external connectors
Multiple Cards Up to six HP NetRAID Series adapters per system
Battery Backup On-board battery backup circuitry provides up to 42 hours of data
retention for 16 MB cache
