Installation and configuration of the HP NetRAID, NetRAID-1 and NetRAID 3Si Adapters

Appendix D Cabling Diagrams
153
Mass Storage Cables
Some of the optional mass storage configurations require additional cables. This
table lists the cables used in configuring the HP NetServer LD Pro mass storage
devices. Only these HP cables and adapters are supported:
Cabling
Diagram
Label
Location Description
C31
Hot swap SCSI backplane-to-
CD-ROM or other device
Narrow SCSI (50 pin)
cable with built-in
terminator
C22
Internal SCSI port-to-hot swap
backplane
Wide SCSI (68 pin) cable
A
Internal narrow (50-pin) to
wide (68-pin) adapter
Narrow-to-Wide SCSI
adapter (50 pin to 68 pin)
B1
I
2
C cable, system board to hot
swap backplane
3-pin I
2
C cable
