Power Supply Upgrade Guide

Chapter 2 HP NetServer LH 3000/3000r: Installing a Power Supply and Fan
7
4. Press the power supply fan module into the connector and swing down the
hinged handle to lock the fan module into place.
Hinged panel rotates up
as you insert the fan module.
Open the hinge of the
fan module, insert the
fan, and close the
hinge.
Figure 2-2. Install Redundant Power Supply Fan Module
5. If you have the rack-mounted version of the NetServer, slide the NetServer
back into the rack chassis and secure it to the rack.
