Power Supply Upgrade Guide

11
3 HP NetServer LH 6000/6000r:
Installing a Power Supply and Fan
To install a redundant power supply, you will follow these steps:
Remove NetServer covers.
Install power supply fan module.
Install power supply.
Finish the installation.
Remove NetServer Covers
1. Close all applications, log off all users, and power down the NetServer.
2. Disconnect all power and telephone cords.
WARNING Before removing the cover, always disconnect both power
cords and unplug telephone cables.
3. Remove appropriate covers as follows:
a. For the pedestal version of your NetServer, remove the front bezel and
the left cover as described in the HP NetServer LH 6000/6000r
Installation Guide.
b. For the rack-mounted version of your NetServer, follow these steps.
See the HP NetServer LH 6000/6000r Installation Guide for further
details.
1. Extend the anti-tip foot.
2. Remove the front bezel.
3. Remove the screws that secure the front of the NetServer to the
rack.
4. From the front of the NetServer, pull the NetServer forward until
you hear the locking device engage with a click.
5. Remove the top cover by loosening the thumbscrew and lifting the
cover away from the NetServer.
