45xx Modular Disk Subsystem Manual for G-Series Releases

Introduction
45xx Modular Disk Subsystem Manual for G-Series Releases—142466
1-3
Customer-Replaceable Units (CRUs)
Table 1-1 shows the product numbers for the components of the 45xx modular disk
subsystem.
Customer-Replaceable Units (CRUs)
Many of the components of the 45xx modular disk subsystem are customer-replaceable
units (CRUs) which can be removed and replaced without using special tools.
Table 1-1. Product Numbers for the 45xx Modular Disk Subsystem
Product
Number Description
4561S 4560 disk drive, single 2-GB
1
4571S 4570 disk drive, single 4-GB
1
4581S 4580 disk drive, single 8-GB
1
4591S 4590 disk drive, single 18-GB
1
455mod8 Disk module, 8-slot (fault tolerant)
455DS Disk module, 8-slot (decision-support)
455UP Disk module upgrade from a 455DS to a 455mod8
6760 ServerNet device adapter
6761 Fiber-optic ServerNet addressable controller (F-SAC)
7158 Frame, modular storage system
2
7159 Pedestal, modular storage system
2
7150 Pedestal, modular storage system, for other device types
7154 Additional fee to enable installation above frame D (see Figure 1-11 on
page 1-18)
7156 Power strip, 4 way, 50 Hz, 250 V
7155 Power strip, 4 way, 60 Hz, 220 V
1. Disk drives can be installed in either type of disk module (455mod8 or 455DS).
2. Two modules (455mod8 or 455DS) can be installed in this frame or pedestal.
Caution. You can use the procedures in this manual to remove and replace failed CRUs, but
do not try to service a removed CRU. Servicing is by replacement only.
