Components of a 45xx Disk Module
Table 1-2 lists Tandem part numbers for 45xx modular disk subsystem CRUs. The
product numbers for the 6760 adapter and part numbers for the fiber-optic cables are
provided in the 6760 ServerNet/DA Manual.
Components of a 45xx Disk Module
Each module consists of (see Figure 1-2 on page 1-5):
•
A front section containing:
°
Up to eight 4560, 4570, 4580, or 4590 disk drives (in any combination)
°
One midplane printed wiring board (PWB) that connects the disk drives to the
back-end boards (BEBs) and power supplies
•
A back section containing:
°
Two small computer system interface (SCSI) back-end boards (BEB) in a
455mod8 disk module
1
°
Two power supplies in a 455mod8 disk module
1
°
One fan CRU containing two fans
1. There is only one BEB and one power supply in the 455DS disk module
Table 1-2. Part Numbers for 45xx Subsystem CRUs
Part
Number
Product
Number Description
104926 4561S 4560 disk drive CRU (2-GB capacity)
109787 4571S 4570 disk drive CRU (4-GB capacity)
126205 4581S 4580 disk drive CRU (8-GB capacity)
136697 4591S 4590 disk drive CRU (18-GB capacity)
105988 n/a Empty drive slot cover plate
101921 n/a Fan CRU without ejector
127441 n/a Fan CRU with ejector
129562 n/a Fan CRU with ejector and change kit (contains adapter brackets
required to replace fan CRU 101921)
129562 n/a Fan CRU change kit (fan CRU with modification hardware)
103223 n/a Module AC power supply
097867 n/a Back-end board (BEB)
106307 n/a Empty module cover plate
The part numbers for fiber-optic cables are listed in the 6760 ServerNet/DA Manual
