45xx Modular Disk Subsystem Manual for G-Series Releases

Index
45xx Modular Disk Subsystem Manual for G-Series Releases—142466
Index-3
M
M
Maximum shipping height 1-2, 1-17
Mirrored 45xx disk drive
preparing to replace 4-3
resuming operations 4-7
Modular storage system
described 1-1
floor space requirements 1-16
height limitations 1-17
height limitations, shipping 1-2
service clearance 1-16
Module
See Disk module
N
Nonmirrored 45xx disk drive
preparing to replace 4-3
resuming operations 4-6
O
Operations
resuming, on a BEB 4-12
resuming, on a disk drive 4-6
Optical carrier signal 1-13
Optical data link 1-13
P
Part numbers
cover plate
empty disk drive slot 1-4
empty module 1-4
disk drives 1-4
fan CRU 1-4
fiber-optic cables 1-4
MICRO DUSTER pressurized air 3-5
TEXPAD alcohol-saturated wiper 3-5
Part numbers, for 45xx disk drives 1-4
Pedestals 1-2, 1-3
Power cord
length 1-16
retainer 1-10
routing 1-10
Power distribution 1-10
Power strip tray 1-10
Power supplies
A/C power cord retainer 1-10
fault tolerance 1-9
installing 4-14
LED 1-9, 3-1
ON/OFF toggle switch 1-10
power distribution 1-9
removing 4-14
replacing 4-13
Product numbers
6760 adapter 1-3
6761 F-SAC 1-3
disk drives 1-3
disk module upgrade kit 1-15
disk modules 1-3
frame, modular storage system 1-3
module upgrade kit 1-3
pedestal, modular storage system 1-3
power strips 1-3
R
Removing
See replacing
Replacing
6760 adapter 4-15
Back-end board (BEB) 4-10
back-end boards (BEBs) 4-10
disk drive 4-1
fan CRU 4-7
nonmirrored disk drive 4-3
power supply 4-13
