Chapter 4 EMULATION
106
Ignore Dots
• Disable. The default.
• Enable. Causes the Code V to expect position values to be
specified in only 1/10ths of an inch. If the dot position is also given,
it is treated as text.
Append Rotated
• Disable. Logos and alphanumeric strings are treated as separate
elements.
• Enable. Appends logos to an alphanumeric string rotated in a
clockwise, counterclockwise, or inverted orientation.
Truncate Alpha
When enabled, this parameter prevents the printing of Error 48
(Element Off Page Error) if alphanumeric data, including spaces,
extends beyond the right side of the form.
True Vert 1/10
• Disable. A vertical 1/10 of an inch parameter is used as 7/72 of an
inch. The absolute move is slightly smaller than expected. For
example, a one inch move would be 70/72 of an inch. Vertical
moves that have the same value will be identical in length.
• Enable. A vertical 1/10 of an inch parameter is used as 1/10 of an
inch. Rounding occurs to the nearest 1/72 of an inch. This can
cause vertical moves that have the same value to differ by
± 1/72 of
an inch.
Absorb after ^PY
• Absorb All. The system ignores all the data and terminator until a
host generated terminator is detected.
• Absorb Motion. Prevents paper motion following a system
terminator in a graphics ^PY command.
• Disable. System terminators following a graphics command are
sent to the printer and result in paper motion.
