Chapter 4 EMULATION
108
Absorb After ^PN
• Disable. All line terminators that immediately follow the ^PN
command are sent to the printer and processed.
• Enable. All line terminators that immediately follow the ^PN
command are ignored.
IGP 110 Compatbl.
This option instructs the Code V to behave similar to the IGP-110 with
respect to certain commands. All new users with new applications
should select the “Disable” option. Selecting this mode insures the
printer will behave as described in this manual.
• Disable. The Code V does not emulate the IGP-110 mode.
• Enable. The Code V emulates the IGP-110 version.
Error Handling
Following are several options which define how errors are reported.
Error msgs
• Enable. Command syntax is checked and error messages printed
when command parameters are incorrect.
• Disable. Error checking and error messages are suppressed.
Error markers
• Enable. Prints the following error markers for those elements that
print beyond the page boundaries:
>> for elements that begin off the right side of the page;
<< for elements that begin at the indicated position but end off the
page;
♦ for elements where the starting position of the command
contains an error other than an off-page error.
