Chapter 4 MAINT / MISC
112
MAINT / MISC
Menu
Hex Dump Mode
A hex code printout (or hex dump) translates all incoming data to
hexadecimal equivalents. A hex dump lists each ASCII data character
received from the host computer, together with its corresponding two-
digit hexadecimal code. Hex dumps can be used to troubleshoot some
types of printer data reception problems. Figure 15 on page 199 shows
a hex dump sample.
Power-Up State
• Online. The printer powers up in the online state.
• Offline. The printer powers up in the offline state.
Display Language
This parameter chooses the language that will appear on the LCD:
English, German, French, Italian, or Spanish.
MAINT/MISC
(from page 69)
Hex Dump
Mode
Power-up
State
Display
Language
Disable*
Enable
Online*
Offline
English*
German
French
Italian
Spanish
* = Factory Default
