Chapter 4 HOST INTERFACE
120
IEEE 1284 Parallel (Bidirectional) Submenu
The IEEE
®
1284 interface supports bidirectional communication.
Configuration of this interface is controlled from the host.
Prime Signal
• Enable. The parallel port will perform a warm start (reboot) if the
host asserts the Prime Signal.
• Disable. The parallel port will not perform a warm start (reboot) if
the host asserts the Prime Signal.
TOF Action
• Reset. A form feed is performed before a warm start when the
prime signal is asserted from the host. This setting is used only if
the Prime Signal parameter is enabled.
• Do Nothing. Nothing occurs before a warm start when the prime
signal is asserted from the host.
Buffer Size in K
This option configures the amount of memory allocated for the IEEE
1284 parallel port buffer. You can specify between 1 and 16 Kbytes, in
1-Kbyte increments.
IEEE 1284
(from page 113)
Prime Signal
TOF Action Buffer Size in
K
Enable*
Disable
Reset*
Do Nothing
1*
(1-16)
* = Factory Default
