Menu
125
DIAGNOSTICS
Printer Tests
These tests are used to check the print quality and operation of the
printer.
NOTE: Your authorized service representative will typically run the
tests. They are described in more detail in the
Maintenance
Manual
.
• Shift Recycle. A sliding alphanumeric pattern which identifies
missing or malformed characters, improper vertical alignment, or
vertical compression.
• All E’s. A pattern of all uppercase E’s which identifies missing
characters, misplaced dots, smeared characters, improper phasing
problems, or light/dark character variations.
DIAGNOSTICS
(from page 69)
Printer Tests
Test Width
Paper Out
Dots
System
Memory
Print Statistics
Shift Recycle*
All E’s
E’s + TOF
All H’s
All Underlines
All Black
Shuttle Slow
Shuttle Fast
Shuttle Only
Phase Printer
217* (500 lpm)
123* (1000 lpm)
62* (1500 lpm)
1 to 2000
Paperout Adj.
Burnin Test
Print Error Log
Clear Error Log
E-net Test Page
1
Full Width*
80 columns
40 dots*
(4-76)
X Megabytes On: X.X hrs.
Print: X.X hrs.
Print Strokes
Print Lines
11 inch Pages
* = Factory Default
1
If Ethernet adapter is present.
