129
New Ribbon
Whenever you install a new ribbon, you must reset the ribbon life to
100%.
Once you install the new ribbon, work your way through the
configuration menus until “New Ribbon” appears on the LCD. Press the
ENTER key to reset the ribbon life to 100%.
Ribbon Action
• Disable. Removes the ink consumption display. RibbonMinder will
continue to monitor how much ink is left in the ribbon.
• Display. Activates the RibbonMinder ink consumption display.
Allows you to continually monitor the percentage of ink left in the
ribbon.
• Fault. Activates a fault message when the display reaches 0%.
RIBBON
MINDER
(from page 69)
New Ribbon
Ribbon Action
Ribbon Size
Ribbon Adjust
Fault Action
Press ENTER
to reset ribbon
life to 100%. A
new ribbon
must be
installed after
setting the
ribbon life to
100%.
Disable*
Display
Fault
60 yards*
(1-255)
0%*
(-99% to 99%)
New Ribbon*
Do Nothing
* = Factory Default
